Ultra small LiPO battery 3.7V 20mAh PD301020

Ultra small LiPO battery 3.7V 20mAh PD301020

Short Description:

3.7V 30mAh lithium polymer battery PD251020 with custom ultra small size,weights only 1g.

Description

Ultra small custom lithium polymer battery
Model: PD301020
Capacity:30mah
Voltage;3.7V
Thickness: 3.0mm (PCM part max 3.3±0.2mm)
Width:10.0±0.2mm
Height:22.0±0.5mm
Weight: about 1.0g
Recommend charging current: 0.2C
Standard charging current: 0.5C
Cable and connectors:standard,recommended or customized are available.
PCB/PCM:
Over-charge voltage 4.25V±0.05V
Over discharge voltage :2.7V±0.1V or 3.0V±0.1V
Over curernt: 60mA(2.7V~4.25V)customized

For more models click here, if you don’t find the right model for your application, please do contact Padre sales,they will recommend you the best one among  more than 3000 models now, you can send inquiry with your requirements at below, and you will get reply very soon.
